General

• Product Name

  • ZENMUSE P1

• Dimensions

  • 198×166×129 mm

• Weight

  • Approx. 800 g

• Power

  • 20W

• IP Rating

  • IP4X

• Supported Aircraft

  • Matrice 300 RTK

• Operating Temperature Range

  • -20° to 50° C (-4° to 122° F)

• Storage Temperature Range

  • -20° to 60° C (-4° to 140° F)

• Absolute Accuracy

  • Horizontal: 3 cm, Vertical: 5 cm *
    * Using Mapping Mission at a GSD of 3 cm and flight speed of 15 m/s, with an 75% front overlap rate and a 55% side overlap rate.

Camera

• Sensor

  • Sensor size (Still): 35.9×24 mm (Full frame)
    Sensor size (Max video recording area): 34×19 mm
    Effective Pixels: 45MP
    Pixel size: 4.4 μm

• Supported Lenses

  • DJI DL 24mm F2.8 LS ASPH (with lens hood and balancing ring/filter), FOV 84°
    DJI DL 35mm F2.8 LS ASPH (with lens hood and balancing ring/filter), FOV 63.5°
    DJI DL 50mm F2.8 LS ASPH (with lens hood and balancing ring/filter), FOV 46.8°

• Supported SD Cards

  • SD: UHS-I rating or above; Max capacity: 512 GB

• Storage Files

  • Photo / GNSS Raw Observation Data/ Image Log File

• Photo Size

  • 3:2 (8192×5460)

• Operation Modes

  • Photo, Video, Playback

• Minimum photo interval

  • 0.7 s

• Shutter Speed

  • Mechanical Shutter Speed: 1/2000*-1 s
    Electronic Shutter Speed: 1/8000-1 s
    *Aperature value no larger than f/5.6

• Aperture Range

  • f/2.8-f/16

• ISO Range

  • Photo: 100-25600
    Video: 100-25600

Video

• Video Format

  • MP4,MOV

• Video Resolution

  • 16:9 (1920×1080)
    16:9 (3840×2160)*
    *Only 35mm lens supported

• Frame Rate

  • 60fps

Gimbal

• Stabilized System

  • 3-axis (tilt, roll, pan)

• Angular Vibration Range

  • ±0.01°

• Mount

  • Detachable DJI SKYPORT

• Mechanical Range

  • Tilt: -130° to +40°;
    Roll: -55° to +55°;
    Pan: ±320°
